Victron Phoenix Inverter 24/800 230V VE.Direct with UK socket

Victron Energy SKU: PIN241801400

More Details
The Victron Phoenix Inverter 24/800 230V VE.Direct with UK socket offers reliable power conversion with smart monitoring, high starting power, and efficient ECO mode for renewable energy system installers.
Documents

Victron Phoenix Inverter 24/800 230V VE.Direct with UK socket

The Victron Phoenix Inverter 24/800 is a 24V DC to 230V AC inverter with VE.Direct communication and a UK BS 1363 socket. It is intended for low-power AC supply from a 24V battery system, with configurable output settings and built-in protection functions.

Key Features
VE.Direct communication port

Supports connection to monitoring and configuration accessories, with access to inverter data such as input/output voltage, load and alarms.

Fully configurable operating settings

Low-voltage alarm, cut-off and restart, output voltage, frequency, and ECO mode can be adjusted to suit the installation.

800VA continuous output

Rated at 800VA at 25°C, with 650W continuous output at 25°C and 560W at 40°C.

1500W peak power

Provides short-duration surge capacity for start-up loads.

IP21 enclosure

Benefits
  • VE.Direct supports monitoring and integration with compatible Victron communication accessories.
  • Configurable protection and output settings allow adjustment to the battery system and load requirements.
  • ECO mode can reduce idle consumption at light load.
  • Screw-terminal DC connection supports straightforward installation.
  • High surge rating helps with brief start-up loads.
Technical Summary

Victron Phoenix Inverter 24/800, 24V DC input, 230VAC output, 50/60Hz adjustable, 800VA continuous output at 25°C, 650W at 25°C / 560W at 40°C, 1500W peak power, 18.4-34.0V input range, IP21 enclosure, UK BS 1363 socket, screw-terminal battery connection, VE.Direct communication, weight 5.5kg, dimensions 105 x 216 x 305 mm.

Installation Notes

DC connection uses screw terminals and the unit includes a remote on/off facility. VE.Direct to USB cable is required for computer connection, and a VE.Direct Bluetooth Smart dongle is required for smartphone, tablet or MacBook connection. For load transfer to another AC source, Victron specifies Filax automatic transfer switch for low power inverter applications.

Efficiency

Maximum efficiency for the 24V range is listed as 89%. ECO mode reduces standby consumption at light load, with default zero-load power in ECO mode listed as 0.9 / 1.4 / 2.6W.

Weight (kg)

5.8

Manufacturer

Victron Energy

Commodity Code

8504408490

Communication

Ethernet and Cellular Communication

Nominal Voltage (V)

62.00

Dimensions (mm) (H x W x D)

280 x 350 x 200

AC Power (kW)

1500.00

Max Current (A)

7

Warranty (Years)

5

Start Up Voltage (V)

36

Max Voltage (V)

231

Inverter Type

AC Coupled

IP Rating

IP22

Max PV Power (kW)

800
