SKU: REN-520075-K
The Renusol ConSole including Mounting Material and U-Profile provides a secure and efficient solution for solar panel installations. Its robust design ensures durability against harsh weather, while easy assembly saves time. This versatile system accommodates various solar panel types, enhancing your offerings and ensuring customer satisfaction.
You need to log in to access the data sheet, user manual, and warranty info.
Renusol ConSole+ is a pre-assembled mounting set for PV modules with hole patterns, supplied with mounting material and U-profile. It is configured for horizontal (landscape) module orientation and a 15° inclination.
Supplied pre-assembled to support quicker on-site handling and installation.
Provides a fixed 15° angle of inclination for the mounting arrangement.
Specified for module frames with holes, with defined hole-distance ranges on the short and long sides.
Configured for horizontal (landscape) module mounting.
Delivered as a complete set with mounting material and U-profile included.
Article number 520075-K. Dimensions 1715 x 1090 x 367 mm. Weight 7.7 kg. Material HDPE, 2.0 mm thickness. Angle of inclination 15°. For module frames with holes. Hole distance short module side: 895-1,014 mm. Hole distance long module side: 690-1,180 mm. Module orientation: horizontal (landscape). TÜV ID: 1111212485.
Pre-assembled set. Includes mounting material and U-profile. Intended for horizontal (landscape) module orientation. Check module frame hole spacing against the stated short- and long-side ranges before installation.
No electrical efficiency data is stated. HDPE is specified as the main material.
Weight (kg)
7.7
Manufacturer
Renusol
Commodity Code
3926909790
Dimensions (mm) (H x W x D)
390 x 1730 x 1100
