SKU: Solis-S2-WL-ST
You need to log in to access the data sheet, user manual, and warranty info.
Data logging stick for Solis inverters, providing WiFi and LAN communication for remote monitoring and data collection. The 4 Pin variant supports RS485 connection to compatible inverters and is intended for monitoring system use.
Supports wireless WiFi network or LAN connection for data transmission to a monitoring system.
Uses RS485 communication to connect up to 10 Solis inverters on one device.
Provides monitoring data and fault alarm functions for connected inverter systems.
Ingress protection rating supports use in exposed installation environments.
Configured through APP or WEB for commissioning and setup.
Solis S2-WL-ST 4 Pin communication stick for Solis inverters. Supports WiFi and LAN communication, RS485 connection, and up to 10 connected inverters. Wireless standard: 802.11b/g/n on 2.4 GHz. Operating voltage: DC 5 V (+/-5%). Power consumption: ?5 W. Data collection interval: 5 minutes. Operating temperature: -30 to +65°C. Protection degree: IP65. Dimensions: 125 x 34 x 49 mm. Weight: 103 g. Configuration method: APP/WEB.
4 Pin variant installs using Insert+Screw method. Connect the inverters by RS485 cables. Configuration is via APP or WEB.
Data collection interval is 5 minutes. Operating power consumption is ?5 W.
Manufacturer
Solis
Commodity Code
8543709099
Dimensions (mm) (H x W x D)
125 x 34 x 49
Weight (kg)
0.1
